VS Code Extension

The PlayCanvas VS Code Extension maps text-based assets from a PlayCanvas project into a local workspace. You can edit scripts and shaders with VS Code or Cursor while the extension handles authentication, branches, type information, and synchronization with the Editor.

The extension is open source on GitHub and licensed under MIT.

Install and Open a Project

1. Install Visual Studio Code or Cursor.
2. Install the PlayCanvas extension from the marketplace used by your editor:
   • VS Code: Visual Studio Marketplace
   • Cursor: Open VSX
3. Select the sign-in notification and authenticate with your PlayCanvas account.
4. Open the Command Palette with Ctrl/Cmd + Shift + P.
5. Run PlayCanvas: Open Project and follow the prompts to choose a project and branch.

The Explorer shows the project's text assets. Open a script to use PlayCanvas-aware type checking, autocomplete, and inline API information. The Collaborators view shows who else is working in the project.

Choose a Sync Mode

Set PlayCanvas: Sync Mode (playcanvas.syncMode) in Settings, then reload the window after changing it.

	Realtime	Pull/Push (Preview)
Best for	Live collaborative editing	External tools and reviewed batches of changes
Synchronization	As you type	Explicit Pull and Push
Conflicts	Merged automatically	Resolved with a three-way merge
Availability	Desktop and web	Desktop only

Realtime Mode

Realtime is the default mode.

• Changes to open files synchronize as you type.
• Changes from collaborators appear in your open files automatically.
• Ctrl/Cmd + S saves the asset in the PlayCanvas Editor.
• Creating, deleting, renaming, or moving files in the Explorer updates the project.
• Ctrl/Cmd + Z and Ctrl/Cmd + Shift + Z undo or redo only your own changes.

Opening a file refreshes it from the server. If another application changes a closed file on disk, realtime mode leaves the local edit on disk but does not submit it. The extension shows a warning directing you to Pull/Push mode.

Pull/Push Mode

Pull/Push keeps filesystem edits local until you choose to synchronize them. This is the correct mode for formatters, compilers, scripts, and AI coding assistants that may edit closed files.

1. Set PlayCanvas: Sync Mode to Pull/Push and reload the window.
2. Open Source Control and select the PlayCanvas repository.
3. Select Pull to establish the latest server state.
4. Edit and save files normally. Local edits appear under Changes.
5. Review the diffs, then select Push.

The PlayCanvas status-bar item shows incoming, outgoing, and conflicted file counts. You can also run PlayCanvas: Pull or PlayCanvas: Push from the Command Palette.

• Pull: Ctrl/Cmd + Alt + Down
• Push: Ctrl/Cmd + Alt + Up

Push is fast-forward only. If the server changed since your last Pull, Push stops without overwriting it. Pull first, resolve any conflicts, and then Push again.

Resolve a Pull/Push Conflict

Conflicted files appear under Merge Changes.

1. Open the conflicted file.
2. Use the merge editor or edit the <<<<<<<, =======, and >>>>>>> sections directly.
3. Keep the intended result, remove all conflict markers, and save the file.
4. Check that the file moved back to Changes, then Push.

To abandon a local edit instead, select its discard action in Source Control. Discard restores the last synchronized version and asks for confirmation first.

Use with AI Coding Assistants

Use Pull/Push mode when an AI coding assistant edits project files. Start the assistant in the mapped project directory and give it the files or behavior in scope, the result you expect, and the checks it should run.

caution

Do not use realtime mode for an external assistant. Realtime mode ignores changes made to closed files by other applications so that stale files cannot overwrite collaborative work.

For example:

Inspect the player movement scripts and make keyboard movement frame-rate independent.
Keep the current controls and public script attributes unchanged.
After editing, check the Problems panel or run the available type check, then summarize
the files changed. Do not modify unrelated assets.

The assistant's edits remain local until you Push. Review every changed file, check diagnostics, Pull the latest server state, resolve any conflicts, and Push. Then launch the project in the PlayCanvas Editor to verify the behavior in its real scene.

Switch Branches

Synchronize or discard your current work before switching branches. Run PlayCanvas: Switch Branch from the Command Palette and select the target branch. The workspace then represents that project branch.

Ignore Files

Create .pcignore in the project root to exclude matching paths from the workspace. Its syntax follows .gitignore, including globs such as *.ts or generated/**.

The extension re-reads .pcignore when it changes. Reload the project to refresh the files on disk after changing its rules.

Troubleshooting

External Changes Do Not Synchronize

Pull/Push is available only in the desktop extension. Confirm that playcanvas.syncMode is pullpush, reload the window, and run Pull before editing with an external tool.

Push Is Blocked

The remote project has changed. Run Pull, resolve any files under Merge Changes, and Push again.

Files Have Conflicting Paths

Run PlayCanvas: Show Path Collisions. Rename the listed assets in the Editor so each asset maps to a unique filesystem path, then reload the project.

The Workspace Looks Stale

Run PlayCanvas: Reload Project. If the problem continues, run PlayCanvas: Report Issue and include the steps that produced it.
