Editor Interface

This page is a tour of the Editor's interface: what each area is for, how to move around your scene, and how to select and move things in it.

The PlayCanvas Editor with its five main areas numbered

  1. Hierarchy: every entity in the scene, as a tree. Select, create, rename, reparent and duplicate entities here.
  2. Viewport: your 3D view of the scene. Select entities by clicking them, and move them with the gizmos.
  3. Inspector: the properties of whatever you have selected, such as an entity's components or an asset's settings. This is where you do most of your editing.
  4. Assets: the files your project uses, such as models, materials, textures, audio and scripts. Drag an asset into the Viewport or onto a property in the Inspector to use it.
  5. Toolbar: the transform tools, undo and redo, the Code Editor, publishing and the Editor's settings.

Above the Viewport, a bar shows the project, branch and scene you're working in. Select Projects in it to go back to the Project Dashboard.

Moving Around the Viewport​

ToDo this
OrbitDrag with the left mouse button.
PanDrag with the middle mouse button, or Shift-drag with the left.
Look aroundDrag with the right mouse button.
ZoomScroll the mouse wheel.
FlyHold W, A, S or D (or the arrow keys) to move, and Q or E to move down or up. Add Shift to go faster.
Frame the selectionPress F. If you lose your way, select an entity and press F to get back to it.

The View Cube in the corner of the Viewport turns the camera to look along an axis. See Viewport for its cameras and render modes.

Selecting and Transforming​

Click an entity in the Viewport or the Hierarchy to select it, and its properties appear in the Inspector. Then use a gizmo to change its transform:

GizmoKeyWhat it does
Translate1Moves the entity.
Rotate2Rotates the entity.
Scale3Scales the entity.

Drag a gizmo's handles to change one axis at a time, or type exact values into Position, Rotation and Scale in the Inspector. Press L to switch the gizmo between world and local axes.

Undo with Ctrl+Z (Cmd+Z on macOS) and redo with Ctrl+Y (Cmd+Y on macOS). Undo only steps back through your own changes, not other people's.

Running Your Scene​

Select Launch at the top right of the Viewport, or press Ctrl+Enter (Cmd+Enter on macOS), to run the current scene in a new tab. The Launch Page stays connected to the Editor, so you can change things and see the result while it runs.

Everything Else​

  • The main menu, under the PlayCanvas logo at the top left, opens the rest of the Editor's tools, such as the Scenes dialog.
  • The cog on the Toolbar opens the Settings for the project and the current scene in the Inspector.
  • Keyboard Shortcuts lists every control. The Controls button on the Toolbar shows them in the Editor.

The Toolbar page describes every button, and you can rearrange the Toolbar to suit you.
